Nexans SIWO-KUL® S30 1.1 kV
Nexans SIWO-KUL® S30 1.1 kV
The SIWO-KUL® S30 1.1 kV cable family is designed to deliver maximum reliability in environments subject to high thermal, electrical and mechanical stress. Thanks to their high flexibility and resistance to thermal shock, oils and other solvents, these cables ensure long-lasting performance in railway, marine and energy industrial applications.
Lee másSIWO-KUL S30 1x6,0 1,1 kV YE
Nexans ref. 10148822
- Embalaje: Cut to length (m)
- Sección del conductor: 6 mm²
- Diámetro exterior nominal: 10,0 mm
SIWO-KUL S30 1x10 1,1 kV YE
Nexans ref. 10148823
- Embalaje: Cut to length (m)
- Sección del conductor: 10 mm²
- Diámetro exterior nominal: 11,0 mm
SIWO-KUL S30 1x16 1,1 kV YE
Nexans ref. 10148814
- Embalaje: Cut to length (m)
- Sección del conductor: 16 mm²
- Diámetro exterior nominal: 13,7 mm
SIWO-KUL S30 1x25 1,1 kV YE
Nexans ref. 60500723
- Embalaje: Cut to length (m)
- Sección del conductor: 25 mm²
- Diámetro exterior nominal: 15,3 mm
SIWO-KUL S30 1x35 1,1 kV YE
Nexans ref. 60500724
- Embalaje: Cut to length (m)
- Sección del conductor: 35 mm²
- Diámetro exterior nominal: 16,5 mm
SIWO-KUL S30 1x50 1,1 kV YE
Nexans ref. 60500725
- Embalaje: Cut to length (m)
- Sección del conductor: 50 mm²
- Diámetro exterior nominal: 19,2 mm
SIWO-KUL S30 1x70 1,1 kV YE
Nexans ref. 60500726
- Embalaje: Cut to length (m)
- Sección del conductor: 70 mm²
- Diámetro exterior nominal: 21,0 mm
SIWO-KUL S30 1x95 1,1 kV YE
Nexans ref. 60006052
- Embalaje: Cut to length (m)
- Sección del conductor: 95 mm²
- Diámetro exterior nominal: 24,3 mm
SIWO-KUL S30 1x120 1,1 kV YE
Nexans ref. 60500727
- Embalaje: Cut to length (m)
- Sección del conductor: 120 mm²
- Diámetro exterior nominal: 26,6 mm
SIWO-KUL S30 1x150 1,1 kV YE
Nexans ref. 10148829
- Embalaje: Cut to length (m)
- Sección del conductor: 150 mm²
- Diámetro exterior nominal: 28,8 mm
SIWO-KUL S30 1x185 1,1 kV YE
Nexans ref. 60009680
- Embalaje: Cut to length (m)
- Sección del conductor: 185 mm²
- Diámetro exterior nominal: 30,8 mm
SIWO-KUL S30 1x240 1,1 kV YE
Nexans ref. 60500729
- Embalaje: Cut to length (m)
- Sección del conductor: 240 mm²
- Diámetro exterior nominal: 33,2 mm
SIWO-KUL S30 1x300 1,1 kV YE
Nexans ref. 60500730
- Embalaje: Cut to length (m)
- Sección del conductor: 300 mm²
- Diámetro exterior nominal: 36,8 mm
Descripción
Descripción
Estándares
-
ProductoCSA C22.2 N° 210-05; IEC 60228; IEC 60502-2
-
InstalaciónIEC 60092
-
EnsayoIEC 60331; IEC 60332-1; IEC 60332-3-22; IEC 60332-3-24; IEC 60754-1; IEC 60754-2; IEC 61034
Applications
The SIWO-KUL® S30 1.1 kV cable range is specifically developed for:
- Connection of rotating machines and transformers
- Wiring of power cabinets, converters and motor controls
- Industrial installations exposed to high mechanical stress
- Vibrating environments requiring long-term flexibility
- Wind, marine and railway OEM applications
Key Advantages
- Excellent flexibility, ideal for compact installations
- Outstanding thermal resistance (-55°C to +180°C continuous operation)
- Metallic braid shielding against electromagnetic interference
- Silicone outer sheath
- Very good resistance to oils, UV and chemical agents
- High durability for long service life
- International approvals and certifications
- Custom-made terminations and lengths available
By choosing the SIWO-KUL® range, you opt for a flexible, robust and durable cable designed to guarantee high performance in the most demanding environments.
