Nexans RZ1-K (AS)
ALSECURE® RZ1-K (AS) 1x120
Nexans ref. 10270893 - Country ref. 3427580767180
- Packaging: Cut to length (m)
- With Green/Yellow core: No
- Number of cores: 1
- Conductor cross-section: 120 mm²
- Flame retardant: IEC 60332-3 Cat. C
- Smoke density: IEC 61034-2
ALSECURE® RZ1-K (AS) 1x150
Nexans ref. 10270894 - Country ref. 3427580767296
- Packaging: Cut to length (m)
- With Green/Yellow core: No
- Number of cores: 1
- Conductor cross-section: 150 mm²
- Flame retardant: IEC 60332-3 Cat. C
- Smoke density: IEC 61034-2
ALSECURE® RZ1-K (AS) 1x185
Nexans ref. 10270896
- Packaging: Cut to length (m)
- With Green/Yellow core: No
- Number of cores: 1
- Conductor cross-section: 185 mm²
- Flame retardant: IEC 60332-3 Cat. C
- Smoke density: IEC 61034-2
ALSECURE® RZ1-K (AS) 1x240
Nexans ref. 10270884
- Packaging: Cut to length (m)
- With Green/Yellow core: No
- Number of cores: 1
- Conductor cross-section: 240 mm²
- Flame retardant: IEC 60332-3 Cat. C
- Smoke density: IEC 61034-2
ALSECURE® RZ1-K (AS) 1x25
Nexans ref. 10270888
- Packaging: Cut to length (m)
- With Green/Yellow core: No
- Number of cores: 1
- Conductor cross-section: 25 mm²
- Flame retardant: IEC 60332-3 Cat. C
- Smoke density: IEC 61034-2
ALSECURE® RZ1-K (AS) 1x35
Nexans ref. 10270889
- Packaging: Cut to length (m)
- With Green/Yellow core: No
- Number of cores: 1
- Conductor cross-section: 35 mm²
- Flame retardant: IEC 60332-3 Cat. C
- Smoke density: IEC 61034-2
ALSECURE® RZ1-K (AS) 1x50
Nexans ref. 10270890
- Packaging: Cut to length (m)
- With Green/Yellow core: No
- Number of cores: 1
- Conductor cross-section: 50 mm²
- Flame retardant: IEC 60332-3 Cat. C
- Smoke density: IEC 61034-2
ALSECURE® RZ1-K (AS) 3x25
Nexans ref. 10271797
- Packaging: Cut to length (m)
- With Green/Yellow core: No
- Number of cores: 3
- Conductor cross-section: 25 mm²
- Flame retardant: IEC 60332-3 Cat. C
- Smoke density: IEC 61034-2
ALSECURE® RZ1-K (AS) 4x25
Nexans ref. 10271799
- Packaging: Cut to length (m)
- With Green/Yellow core: No
- Number of cores: 4
- Conductor cross-section: 25 mm²
- Flame retardant: IEC 60332-3 Cat. C
- Smoke density: IEC 61034-2
ALSECURE® RZ1-K (AS) 4x35
Nexans ref. 10271800
- Packaging: Cut to length (m)
- With Green/Yellow core: No
- Number of cores: 4
- Conductor cross-section: 35 mm²
- Flame retardant: IEC 60332-3 Cat. C
- Smoke density: IEC 61034-2
ALSECURE® RZ1-K (AS) 4x50
Nexans ref. 10271801
- Packaging: Cut to length (m)
- With Green/Yellow core: No
- Number of cores: 4
- Conductor cross-section: 50 mm²
- Flame retardant: IEC 60332-3 Cat. C
- Smoke density: IEC 61034-2
ALSECURE® RZ1-K (AS) 5G25
Nexans ref. 10270992
- Packaging: Cut to length (m)
- With Green/Yellow core: Yes
- Number of cores: 5
- Conductor cross-section: 25 mm²
- Flame retardant: IEC 60332-3 Cat. C
- Smoke density: IEC 61034-2
ALSECURE® RZ1-K (AS) 5G35
Nexans ref. 10271804
- Packaging: Cut to length (m)
- With Green/Yellow core: Yes
- Number of cores: 5
- Conductor cross-section: 35 mm²
- Flame retardant: IEC 60332-3 Cat. C
- Smoke density: IEC 61034-2
ALSECURE® RZ1-K (AS) MOBIWAY 3G1.5 D200
Nexans ref. 10279405 - Country ref. 102-336
- Packaging: Drum (200m)
- With Green/Yellow core: Yes
- Number of cores: 3
- Conductor cross-section: 1.5 mm²
- Flame retardant: IEC 60332-1-2
- Smoke density: IEC 61034
ALSECURE® RZ1-K (AS) MOBIWAY 3G2.5 D150
Nexans ref. 10279406 - Country ref. 102-336
- Packaging: Drum (150m)
- With Green/Yellow core: Yes
- Number of cores: 3
- Conductor cross-section: 2.5 mm²
- Flame retardant: IEC 60332-1-2
- Smoke density: IEC 61034
ALSECURE® RZ1-K (AS), 1x16 mm²
Nexans ref. 10082421 - Country ref. 102-103-336
- Packaging: Cut to length (m)
- With Green/Yellow core: No
- Number of cores: 1
- Conductor cross-section: 16 mm²
- Flame retardant: IEC 60332-3 Cat. C
- Smoke density: IEC 61034
ALSECURE® RZ1-K (AS), 1x4 mm²
Nexans ref. 10099305 - Country ref. 102-103
- Packaging: Cut to length (m)
- With Green/Yellow core: No
- Number of cores: 1
- Conductor cross-section: 4 mm²
- Flame retardant: IEC 60332-3 Cat. C
- Smoke density: IEC 61034-2
ALSECURE® RZ1-K (AS), 1x6 mm²
Nexans ref. 10099306 - Country ref. 102-103
- Packaging: Cut to length (m)
- With Green/Yellow core: No
- Number of cores: 1
- Conductor cross-section: 6 mm²
- Flame retardant: IEC 60332-3 Cat. C
- Smoke density: IEC 61034-2
ALSECURE® RZ1-K (AS), 2x1.5 mm²
Nexans ref. 10085630 - Country ref. 102-103-336
- Packaging: Cut to length (m)
- With Green/Yellow core: No
- Number of cores: 2
- Conductor cross-section: 1.5 mm²
- Flame retardant: IEC 60332-1-2
- Smoke density: IEC 61034
ALSECURE® RZ1-K (AS), 2x1.5 mm², R100
Nexans ref. 10085629 - Country ref. 102-103-336
- Packaging: Coil (m)
- With Green/Yellow core: No
- Number of cores: 2
- Conductor cross-section: 1.5 mm²
- Flame retardant: IEC 60332-1-2
- Smoke density: IEC 61034
ALSECURE® RZ1-K (AS), 2x10 mm²
Nexans ref. 10082472 - Country ref. 102-103
- Packaging: Cut to length (m)
- With Green/Yellow core: No
- Number of cores: 2
- Conductor cross-section: 10 mm²
- Flame retardant: IEC 60332-3 Cat. C
- Smoke density: IEC 61034-2
ALSECURE® RZ1-K (AS), 2x16 mm²
Nexans ref. 10082473 - Country ref. 102-103
- Packaging: Cut to length (m)
- With Green/Yellow core: No
- Number of cores: 2
- Conductor cross-section: 16 mm²
- Flame retardant: IEC 60332-3 Cat. C
- Smoke density: IEC 61034-2
ALSECURE® RZ1-K (AS), 2x2.5 mm²
Nexans ref. 10085743 - Country ref. 102-103-336
- Packaging: Cut to length (m)
- With Green/Yellow core: No
- Number of cores: 2
- Conductor cross-section: 2.5 mm²
- Flame retardant: IEC 60332-1-2
- Smoke density: IEC 61034
ALSECURE® RZ1-K (AS), 2x4 mm²
Nexans ref. 10085810 - Country ref. 102-103-336
- Packaging: Cut to length (m)
- With Green/Yellow core: No
- Number of cores: 2
- Conductor cross-section: 4 mm²
- Flame retardant: IEC 60332-1-2
- Smoke density: IEC 61034
ALSECURE® RZ1-K (AS), 2x4 mm², R100
Nexans ref. 10085791 - Country ref. 102-103-336
- Packaging: Coil (m)
- With Green/Yellow core: No
- Number of cores: 2
- Conductor cross-section: 4 mm²
- Flame retardant: IEC 60332-1-2
- Smoke density: IEC 61034
ALSECURE® RZ1-K (AS), 2x6 mm²
Nexans ref. 10085793 - Country ref. 102-103-336
- Packaging: Cut to length (m)
- With Green/Yellow core: No
- Number of cores: 2
- Conductor cross-section: 6 mm²
- Flame retardant: IEC 60332-1-2
- Smoke density: IEC 61034
ALSECURE® RZ1-K (AS), 2x6 mm², R100
Nexans ref. 10085792 - Country ref. 102-103-336
- Packaging: Coil (m)
- With Green/Yellow core: No
- Number of cores: 2
- Conductor cross-section: 6 mm²
- Flame retardant: IEC 60332-1-2
- Smoke density: IEC 61034
ALSECURE® RZ1-K (AS), 3G1.5 mm²
Nexans ref. 10082374 - Country ref. 102-103-336
- Packaging: Cut to length (m)
- With Green/Yellow core: Yes
- Number of cores: 3
- Conductor cross-section: 1.5 mm²
- Flame retardant: IEC 60332-1-2
- Smoke density: IEC 61034
ALSECURE® RZ1-K (AS), 3G1.5 mm², R100
Nexans ref. 10082375 - Country ref. 102-103-336
- Packaging: Coil (m)
- With Green/Yellow core: Yes
- Number of cores: 3
- Conductor cross-section: 1.5 mm²
- Flame retardant: IEC 60332-1-2
- Smoke density: IEC 61034
ALSECURE® RZ1-K (AS), 3G10 mm²
Nexans ref. 10082474 - Country ref. 102-103
- Packaging: Cut to length (m)
- With Green/Yellow core: Yes
- Number of cores: 3
- Conductor cross-section: 10 mm²
- Flame retardant: IEC 60332-3 Cat. C
- Smoke density: IEC 61034-2
ALSECURE® RZ1-K (AS), 3G2.5 mm²
Nexans ref. 10082379 - Country ref. 102-103-336
- Packaging: Cut to length (m)
- With Green/Yellow core: Yes
- Number of cores: 3
- Conductor cross-section: 2.5 mm²
- Flame retardant: IEC 60332-1-2
- Smoke density: IEC 61034
ALSECURE® RZ1-K (AS), 3G2.5 mm², R100
Nexans ref. 10082378 - Country ref. 102-103-336
- Packaging: Coil (m)
- With Green/Yellow core: Yes
- Number of cores: 3
- Conductor cross-section: 2.5 mm²
- Flame retardant: IEC 60332-1-2
- Smoke density: IEC 61034
ALSECURE® RZ1-K (AS), 3G4 mm²
Nexans ref. 10085984 - Country ref. 102-103-336
- Packaging: Cut to length (m)
- With Green/Yellow core: Yes
- Number of cores: 3
- Conductor cross-section: 4 mm²
- Flame retardant: IEC 60332-1-2
- Smoke density: IEC 61034
ALSECURE® RZ1-K (AS), 3G4 mm², R100
Nexans ref. 10086306 - Country ref. 102-103-336
- Packaging: Coil (m)
- With Green/Yellow core: Yes
- Number of cores: 3
- Conductor cross-section: 4 mm²
- Flame retardant: IEC 60332-1-2
- Smoke density: IEC 61034
ALSECURE® RZ1-K (AS), 3G6 mm²
Nexans ref. 10086307 - Country ref. 102-103-336
- Packaging: Cut to length (m)
- With Green/Yellow core: Yes
- Number of cores: 3
- Conductor cross-section: 6 mm²
- Flame retardant: IEC 60332-1-2
- Smoke density: IEC 61034
ALSECURE® RZ1-K (AS), 3G6 mm², R100
Nexans ref. 10086308 - Country ref. 102-103-336
- Packaging: Coil (m)
- With Green/Yellow core: Yes
- Number of cores: 3
- Conductor cross-section: 6 mm²
- Flame retardant: IEC 60332-1-2
- Smoke density: IEC 61034
ALSECURE® RZ1-K (AS), 4G1.5 mm²
Nexans ref. 10086320 - Country ref. 102-103-336
- Packaging: Cut to length (m)
- With Green/Yellow core: Yes
- Number of cores: 4
- Conductor cross-section: 1.5 mm²
- Flame retardant: IEC 60332-1-2
- Smoke density: IEC 61034
ALSECURE® RZ1-K (AS), 4G1.5 mm², R100
Nexans ref. 10086311 - Country ref. 102-103-336
- Packaging: Coil (m)
- With Green/Yellow core: Yes
- Number of cores: 4
- Conductor cross-section: 1.5 mm²
- Flame retardant: IEC 60332-1-2
- Smoke density: IEC 61034
ALSECURE® RZ1-K (AS), 4G10 mm²
Nexans ref. 10082477 - Country ref. 102-103
- Packaging: Cut to length (m)
- With Green/Yellow core: Yes
- Number of cores: 4
- Conductor cross-section: 10 mm²
- Flame retardant: IEC 60332-3 Cat. C
- Smoke density: IEC 61034-2
ALSECURE® RZ1-K (AS), 4G2.5 mm²
Nexans ref. 10086321 - Country ref. 102-103-336
- Packaging: Cut to length (m)
- With Green/Yellow core: Yes
- Number of cores: 4
- Conductor cross-section: 2.5 mm²
- Flame retardant: IEC 60332-1-2
- Smoke density: IEC 61034
ALSECURE® RZ1-K (AS), 4G2.5 mm², R100
Nexans ref. 10086323 - Country ref. 102-103-336
- Packaging: Coil (m)
- With Green/Yellow core: Yes
- Number of cores: 4
- Conductor cross-section: 2.5 mm²
- Flame retardant: IEC 60332-1-2
- Smoke density: IEC 61034
ALSECURE® RZ1-K (AS), 4G4 mm²
Nexans ref. 10086464 - Country ref. 102-103-336
- Packaging: Cut to length (m)
- With Green/Yellow core: Yes
- Number of cores: 4
- Conductor cross-section: 4 mm²
- Flame retardant: IEC 60332-1-2
- Smoke density: IEC 61034
ALSECURE® RZ1-K (AS), 4G4 mm², R100
Nexans ref. 10086414 - Country ref. 102-103-336
- Packaging: Coil (m)
- With Green/Yellow core: Yes
- Number of cores: 4
- Conductor cross-section: 4 mm²
- Flame retardant: IEC 60332-1-2
- Smoke density: IEC 61034
ALSECURE® RZ1-K (AS), 4G6 mm²
Nexans ref. 10086466 - Country ref. 102-103-336
- Packaging: Cut to length (m)
- With Green/Yellow core: Yes
- Number of cores: 4
- Conductor cross-section: 6 mm²
- Flame retardant: IEC 60332-1-2
- Smoke density: IEC 61034
ALSECURE® RZ1-K (AS), 4G6 mm², R100
Nexans ref. 10086467 - Country ref. 102-103-336
- Packaging: Coil (m)
- With Green/Yellow core: Yes
- Number of cores: 4
- Conductor cross-section: 6 mm²
- Flame retardant: IEC 60332-1-2
- Smoke density: IEC 61034
ALSECURE® RZ1-K (AS), 4X6 mm²
Nexans ref. 10243269 - Country ref. 102-103-336
- With Green/Yellow core: No
- Number of cores: 4
- Conductor cross-section: 6 mm²
- Flame retardant: IEC 60332-1-2
- Smoke density: IEC 61034
ALSECURE® RZ1-K (AS), 5G1.5 mm²
Nexans ref. 10086471 - Country ref. 102-103-336
- Packaging: Cut to length (m)
- With Green/Yellow core: Yes
- Number of cores: 5
- Conductor cross-section: 1.5 mm²
- Flame retardant: IEC 60332-1-2
- Smoke density: IEC 61034
ALSECURE® RZ1-K (AS), 5G1.5 mm², R100
Nexans ref. 10086470 - Country ref. 102-103-336
- Packaging: Coil (m)
- With Green/Yellow core: Yes
- Number of cores: 5
- Conductor cross-section: 1.5 mm²
- Flame retardant: IEC 60332-1-2
- Smoke density: IEC 61034
ALSECURE® RZ1-K (AS), 5G10 mm²
Nexans ref. 10082484 - Country ref. 102-103
- Packaging: Cut to length (m)
- With Green/Yellow core: Yes
- Number of cores: 5
- Conductor cross-section: 10 mm²
- Flame retardant: IEC 60332-3 Cat. C
- Smoke density: IEC 61034-2
ALSECURE® RZ1-K (AS), 5G16 mm²
Nexans ref. 10082485 - Country ref. 102-103
- Packaging: Cut to length (m)
- With Green/Yellow core: Yes
- Number of cores: 5
- Conductor cross-section: 16 mm²
- Flame retardant: IEC 60332-3 Cat. C
- Smoke density: IEC 61034-2
ALSECURE® RZ1-K (AS), 5G2.5 mm²
Nexans ref. 10086473 - Country ref. 102-103-336
- Packaging: Cut to length (m)
- With Green/Yellow core: Yes
- Number of cores: 5
- Conductor cross-section: 2.5 mm²
- Flame retardant: IEC 60332-1-2
- Smoke density: IEC 61034
ALSECURE® RZ1-K (AS), 5G2.5 mm², R100
Nexans ref. 10086472 - Country ref. 102-103-336
- Packaging: Coil (m)
- With Green/Yellow core: Yes
- Number of cores: 5
- Conductor cross-section: 2.5 mm²
- Flame retardant: IEC 60332-1-2
- Smoke density: IEC 61034
ALSECURE® RZ1-K (AS), 5G4 mm²
Nexans ref. 10086486 - Country ref. 102-103-336
- Packaging: Cut to length (m)
- With Green/Yellow core: Yes
- Number of cores: 5
- Conductor cross-section: 4 mm²
- Flame retardant: IEC 60332-1-2
- Smoke density: IEC 61034
ALSECURE® RZ1-K (AS), 5G4 mm², R100
Nexans ref. 10086492 - Country ref. 102-103-336
- Packaging: Coil (m)
- With Green/Yellow core: Yes
- Number of cores: 5
- Conductor cross-section: 4 mm²
- Flame retardant: IEC 60332-1-2
- Smoke density: IEC 61034
ALSECURE® RZ1-K (AS), 5G6 mm²
Nexans ref. 10086493 - Country ref. 102-103-336
- Packaging: Cut to length (m)
- With Green/Yellow core: Yes
- Number of cores: 5
- Conductor cross-section: 6 mm²
- Flame retardant: IEC 60332-1-2
- Smoke density: IEC 61034
ALSECURE® RZ1-K (AS)1x70
Nexans ref. 10270891
- Packaging: Cut to length (m)
- With Green/Yellow core: No
- Number of cores: 1
- Conductor cross-section: 70 mm²
- Flame retardant: IEC 60332-3 Cat. C
- Smoke density: IEC 61034-2
ALSECURE® RZ1-K (AS)1x95
Nexans ref. 10270892
- Packaging: Cut to length (m)
- With Green/Yellow core: No
- Number of cores: 1
- Conductor cross-section: 95 mm²
- Flame retardant: IEC 60332-3 Cat. C
- Smoke density: IEC 61034-2
DRUM RZ1K-3x1,5-M (75m)
Nexans ref. 10270268 - Country ref. 102-336
- Packaging: Drum (75m)
- With Green/Yellow core: No
- Number of cores: 3
- Conductor cross-section: 1.5 mm²
- Flame retardant: IEC 60332-1-2
- Smoke density: IEC 61034
Description
Description
Standards
-
ProductIEC 60502; UNE 21123
-
TestEN 50265-2-1; EN 50267-2-2; EN 50268; IEC 60332-1; IEC 60332-3 Cat.C; IEC 60754-1; IEC 60754-2; IEC 61034
APPLICATION
RZ1-K Cable NON PROPAGATOR OF FIRE.
Installation in local of difficult ventilation, publics, evacuation itineraries, tunnels...
Almost null toxicity. Provoked gases when burning almost transparent, facilitating evacuation
Flexible, halogen-free cable used in distribution networks, connections, installations in public places. lt is recammended to use it in installations where there is a risk of fire and greater advantages are needed in the event of a fire, such as the low emission of toxic, corrosive, low opacity fumes, in particular to protect people and equipment, and evacuate people.
CORE COLOURS
- 1 core = Black
- 2 cores = Brown + Light blue
- 3 cores = Brown + Black + Grey or Brown + Light blue + Green-Yellow
- 4 cores = Brown + Black + Grey + Light blue or Green-Yellow
- 5 cores = Brown + Black + Grey + Light blue + Black or Green-Yellow
MARKING
ALSECURE ® Nexans RZ1 - K(AS) -0,6/1 KV - N (x or G) S mm² - Fab.Year- AENOR
- N = number of cores
- S = section in mm²
- G = with Green-Yellow
- x = without Green-Yellow
MOB
ALSECURE - Protección ante el fuego
Gama compatible con MOBIWAY
PHOTO AMBIANCE 1
PHOTO AMBIANCE 2
Photo Ambiance
Characteristics
Characteristics
Construction characteristics
Construction characteristics
Conductor material
Electrolytic copper
Sheath colour
Green
Outer sheath
Polyolefin
Insulation
Extruded XLPE compound
Conductor shape
Circular
With smaller neutral conductor
No
Dimensional characteristics
Dimensional characteristics
Neutral conductor section (when smaller)
- mm²
Electrical characteristics
Electrical characteristics
Max. DC resistance of the conductor at 20°C
- Ohm/km
Fire safety characteristics
Fire safety characteristics
Fire retardant
IEC 60332-3-24 (cat C)
Gases corrosivity
IEC 60754-2
Halogen free
IEC 60754-1
Resources
Resources
Documentation
PEP ECOPASSPORT RZ1-K 1.5 and 2.5 mm²
pdf — 4.4 MB
BROCHURE MOBIWAY MOB
pdf — 3.8 MB
PEP ECOPASSPORT RZ1-K MULTI
pdf — 5.1 MB
PEP ECOPASSPORT RZ1-K MONO
pdf — 5.1 MB
Current capacity table XLPE insulation multicore three phase
| Conductor cross-section | A2 - Multi-core cable in conduit in a thermally insulated wall | B2 - Multi-core cable in conduit on a wooden wall | C - Single-core or multi-core cable on a wooden wall | D1 - Single-core or Multi-core cable in ducts in the ground | D2 - Single-core or Multi-core cables designed to be buried directly in the ground | E - Multi-core cable in free air | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| mm² | Cu | Al | Cu | Al | Cu | Al | Cu | Al | Cu | Al | Cu | Al |
| 1.5 | 16.5 | 0.0 | 19.5 | 0.0 | 22.0 | 0.0 | 25.0 | 0.0 | 23.0 | 0.0 | 26.0 | 0.0 |
| 2.5 | 22.0 | 19.5 | 26.0 | 23.0 | 30.0 | 26.0 | 33.0 | 26.0 | 30.0 | 0.0 | 36.0 | 28.0 |
| 4.0 | 30.0 | 26.0 | 35.0 | 31.0 | 40.0 | 35.0 | 43.0 | 33.0 | 39.0 | 0.0 | 49.0 | 38.0 |
| 6.0 | 38.0 | 33.0 | 44.0 | 40.0 | 52.0 | 45.0 | 53.0 | 42.0 | 49.0 | 0.0 | 63.0 | 49.0 |
| 10.0 | 51.0 | 45.0 | 60.0 | 54.0 | 71.0 | 62.0 | 71.0 | 55.0 | 65.0 | 0.0 | 86.0 | 67.0 |
| 16.0 | 68.0 | 60.0 | 80.0 | 72.0 | 96.0 | 84.0 | 91.0 | 71.0 | 84.0 | 76.0 | 115.0 | 91.0 |
| 25.0 | 89.0 | 78.0 | 105.0 | 94.0 | 119.0 | 101.0 | 116.0 | 90.0 | 107.0 | 98.0 | 149.0 | 108.0 |
| 35.0 | 109.0 | 96.0 | 128.0 | 115.0 | 147.0 | 126.0 | 139.0 | 108.0 | 129.0 | 117.0 | 185.0 | 135.0 |
| 50.0 | 130.0 | 115.0 | 154.0 | 138.0 | 179.0 | 154.0 | 164.0 | 128.0 | 153.0 | 139.0 | 225.0 | 164.0 |
| 70.0 | 164.0 | 145.0 | 194.0 | 175.0 | 229.0 | 198.0 | 203.0 | 158.0 | 188.0 | 170.0 | 289.0 | 211.0 |
| 95.0 | 197.0 | 175.0 | 233.0 | 210.0 | 278.0 | 241.0 | 239.0 | 186.0 | 226.0 | 204.0 | 352.0 | 257.0 |
| 120.0 | 227.0 | 201.0 | 268.0 | 242.0 | 322.0 | 280.0 | 271.0 | 211.0 | 257.0 | 233.0 | 410.0 | 300.0 |
| 150.0 | 259.0 | 230.0 | 300.0 | 261.0 | 371.0 | 324.0 | 306.0 | 238.0 | 287.0 | 261.0 | 473.0 | 346.0 |
| 185.0 | 295.0 | 262.0 | 340.0 | 300.0 | 424.0 | 371.0 | 343.0 | 267.0 | 324.0 | 296.0 | 542.0 | 397.0 |
| 240.0 | 346.0 | 307.0 | 398.0 | 358.0 | 500.0 | 439.0 | 395.0 | 307.0 | 375.0 | 343.0 | 641.0 | 470.0 |
| 300.0 | 396.0 | 352.0 | 455.0 | 415.0 | 576.0 | 508.0 | 446.0 | 346.0 | 419.0 | 386.0 | 741.0 | 543.0 |
Current capacity table XLPE insulation single core three phase
| Conductor cross-section | A1 - Insulated conductors in conduit in a thermally insulated wall | B1 - Insulated conductors in conduit on a wooden wall | C - Single-core or multi-core cable on a wooden wall | D1 - Single-core or Multi-core cable in ducts in the ground | D2 - Single-core or Multi-core cables designed to be buried directly in the ground | F - Single-core flat cables, touching in free air | Ft - Single-core trefoil cables, touching in free air | G - Single-core horizontal spaced | Gv - Single-core flat vertical spaced | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| mm² | Cu | Al | Cu | Al | Cu | Al | Cu | Al | Cu | Al | Cu | Al | Cu | Al | Cu | Al | Cu | Al |
| 1.5 | 17.0 | 0.0 | 20.0 | 0.0 | 22.0 | 0.0 | 21.0 | 0.0 | 23.0 | 0.0 | 0.0 | 0.0 | 0.0 | 0.0 | 0.0 | 0.0 | 0.0 | 0.0 |
| 2.5 | 23.0 | 19.0 | 28.0 | 22.0 | 30.0 | 24.0 | 28.0 | 22.0 | 30.0 | 0.0 | 0.0 | 0.0 | 0.0 | 0.0 | 0.0 | 0.0 | 0.0 | 0.0 |
| 4.0 | 31.0 | 25.0 | 37.0 | 29.0 | 40.0 | 32.0 | 36.0 | 28.0 | 39.0 | 0.0 | 0.0 | 0.0 | 0.0 | 0.0 | 0.0 | 0.0 | 0.0 | 0.0 |
| 6.0 | 40.0 | 32.0 | 48.0 | 38.0 | 52.0 | 41.0 | 44.0 | 35.0 | 49.0 | 0.0 | 0.0 | 0.0 | 0.0 | 0.0 | 0.0 | 0.0 | 0.0 | 0.0 |
| 10.0 | 54.0 | 44.0 | 66.0 | 52.0 | 71.0 | 57.0 | 58.0 | 46.0 | 65.0 | 0.0 | 0.0 | 0.0 | 0.0 | 0.0 | 0.0 | 0.0 | 0.0 | 0.0 |
| 16.0 | 73.0 | 58.0 | 88.0 | 71.0 | 96.0 | 76.0 | 75.0 | 59.0 | 84.0 | 64.0 | 0.0 | 0.0 | 0.0 | 0.0 | 0.0 | 0.0 | 0.0 | 0.0 |
| 25.0 | 95.0 | 76.0 | 117.0 | 93.0 | 119.0 | 90.0 | 96.0 | 75.0 | 107.0 | 82.0 | 141.0 | 103.0 | 135.0 | 182.0 | 103.0 | 138.0 | 161.0 | 122.0 |
| 35.0 | 117.0 | 94.0 | 144.0 | 116.0 | 147.0 | 112.0 | 115.0 | 90.0 | 129.0 | 98.0 | 176.0 | 129.0 | 169.0 | 226.0 | 129.0 | 172.0 | 201.0 | 153.0 |
| 50.0 | 141.0 | 113.0 | 175.0 | 140.0 | 179.0 | 136.0 | 135.0 | 106.0 | 153.0 | 117.0 | 216.0 | 159.0 | 207.0 | 275.0 | 159.0 | 210.0 | 246.0 | 188.0 |
| 70.0 | 179.0 | 142.0 | 222.0 | 179.0 | 229.0 | 174.0 | 167.0 | 130.0 | 188.0 | 144.0 | 279.0 | 206.0 | 268.0 | 353.0 | 206.0 | 271.0 | 318.0 | 244.0 |
| 95.0 | 216.0 | 171.0 | 269.0 | 217.0 | 278.0 | 211.0 | 197.0 | 154.0 | 226.0 | 172.0 | 342.0 | 253.0 | 328.0 | 430.0 | 253.0 | 332.0 | 389.0 | 300.0 |
| 120.0 | 249.0 | 197.0 | 312.0 | 251.0 | 322.0 | 245.0 | 223.0 | 174.0 | 257.0 | 197.0 | 400.0 | 296.0 | 383.0 | 500.0 | 296.0 | 387.0 | 454.0 | 351.0 |
| 150.0 | 285.0 | 226.0 | 342.0 | 267.0 | 371.0 | 283.0 | 251.0 | 197.0 | 287.0 | 220.0 | 464.0 | 343.0 | 444.0 | 577.0 | 343.0 | 448.0 | 527.0 | 408.0 |
| 185.0 | 324.0 | 256.0 | 384.0 | 300.0 | 424.0 | 323.0 | 281.0 | 220.0 | 324.0 | 250.0 | 533.0 | 395.0 | 510.0 | 661.0 | 395.0 | 515.0 | 605.0 | 470.0 |
| 240.0 | 380.0 | 300.0 | 450.0 | 351.0 | 500.0 | 382.0 | 324.0 | 253.0 | 375.0 | 290.0 | 634.0 | 471.0 | 607.0 | 781.0 | 471.0 | 611.0 | 719.0 | 561.0 |
| 300.0 | 435.0 | 344.0 | 514.0 | 402.0 | 576.0 | 440.0 | 365.0 | 286.0 | 419.0 | 326.0 | 736.0 | 547.0 | 703.0 | 902.0 | 547.0 | 708.0 | 833.0 | 652.0 |
Current capacity table XLPE insulation single core single phase
| Conductor cross-section | A1 - Insulated conductors in conduit in a thermally insulated wall | B1 - Insulated conductors in conduit on a wooden wall | C - Single-core or multi-core cable on a wooden wall | D1 - Single-core or Multi-core cable in ducts in the ground | D2 - Single-core or Multi-core cables designed to be buried directly in the ground | F - Single-core flat cables, touching in free air | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| mm² | Cu | Al | Cu | Al | Cu | Al | Cu | Al | Cu | Al | Cu | Al |
| 1.5 | 19.0 | 0.0 | 23.0 | 0.0 | 24.0 | 0.0 | 25.0 | 0.0 | 27.0 | 0.0 | 0.0 | 0.0 |
| 2.5 | 26.0 | 20.0 | 31.0 | 25.0 | 33.0 | 26.0 | 33.0 | 26.0 | 35.0 | 0.0 | 0.0 | 0.0 |
| 4.0 | 35.0 | 27.0 | 42.0 | 33.0 | 45.0 | 35.0 | 43.0 | 33.0 | 46.0 | 0.0 | 0.0 | 0.0 |
| 6.0 | 45.0 | 35.0 | 54.0 | 43.0 | 58.0 | 45.0 | 53.0 | 42.0 | 58.0 | 0.0 | 0.0 | 0.0 |
| 10.0 | 61.0 | 48.0 | 75.0 | 59.0 | 80.0 | 62.0 | 71.0 | 55.0 | 77.0 | 0.0 | 0.0 | 0.0 |
| 16.0 | 81.0 | 64.0 | 100.0 | 79.0 | 107.0 | 84.0 | 91.0 | 71.0 | 100.0 | 76.0 | 0.0 | 0.0 |
| 25.0 | 106.0 | 84.0 | 133.0 | 105.0 | 138.0 | 101.0 | 116.0 | 90.0 | 129.0 | 98.0 | 161.0 | 121.0 |
| 35.0 | 131.0 | 103.0 | 164.0 | 130.0 | 171.0 | 126.0 | 139.0 | 108.0 | 155.0 | 117.0 | 200.0 | 150.0 |
| 50.0 | 158.0 | 125.0 | 198.0 | 157.0 | 209.0 | 154.0 | 164.0 | 128.0 | 183.0 | 139.0 | 242.0 | 184.0 |
| 70.0 | 200.0 | 158.0 | 253.0 | 200.0 | 269.0 | 198.0 | 203.0 | 158.0 | 225.0 | 170.0 | 310.0 | 237.0 |
| 95.0 | 241.0 | 191.0 | 306.0 | 242.0 | 328.0 | 241.0 | 239.0 | 186.0 | 270.0 | 204.0 | 377.0 | 289.0 |
| 120.0 | 278.0 | 220.0 | 354.0 | 281.0 | 382.0 | 280.0 | 271.0 | 211.0 | 306.0 | 233.0 | 437.0 | 337.0 |
| 150.0 | 318.0 | 253.0 | 393.0 | 307.0 | 441.0 | 324.0 | 306.0 | 238.0 | 343.0 | 261.0 | 504.0 | 389.0 |
| 185.0 | 362.0 | 288.0 | 449.0 | 351.0 | 506.0 | 371.0 | 343.0 | 267.0 | 387.0 | 296.0 | 575.0 | 447.0 |
| 240.0 | 424.0 | 338.0 | 528.0 | 412.0 | 599.0 | 439.0 | 395.0 | 307.0 | 448.0 | 343.0 | 679.0 | 530.0 |
| 300.0 | 486.0 | 387.0 | 603.0 | 471.0 | 693.0 | 508.0 | 446.0 | 346.0 | 502.0 | 386.0 | 783.0 | 613.0 |
Current capacity table XLPE insulation multicore single phase
| Conductor cross-section | A2 - Multi-core cable in conduit in a thermally insulated wall | B2 - Multi-core cable in conduit on a wooden wall | C - Single-core or multi-core cable on a wooden wall | D1 - Single-core or Multi-core cable in ducts in the ground | D2 - Single-core or Multi-core cables designed to be buried directly in the ground | E - Multi-core cable in free air | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| mm² | Cu | Al | Cu | Al | Cu | Al | Cu | Al | Cu | Al | Cu | Al |
| 1.5 | 18.5 | 0.0 | 22.0 | 0.0 | 24.0 | 0.0 | 25.0 | 0.0 | 27.0 | 0.0 | 26.0 | 0.0 |
| 2.5 | 25.0 | 19.5 | 30.0 | 23.0 | 33.0 | 26.0 | 33.0 | 26.0 | 35.0 | 0.0 | 36.0 | 28.0 |
| 4.0 | 33.0 | 26.0 | 40.0 | 31.0 | 45.0 | 35.0 | 43.0 | 33.0 | 46.0 | 0.0 | 49.0 | 38.0 |
| 6.0 | 42.0 | 33.0 | 51.0 | 40.0 | 58.0 | 45.0 | 53.0 | 42.0 | 58.0 | 0.0 | 63.0 | 49.0 |
| 10.0 | 57.0 | 45.0 | 69.0 | 54.0 | 80.0 | 62.0 | 71.0 | 55.0 | 77.0 | 0.0 | 86.0 | 67.0 |
| 16.0 | 76.0 | 60.0 | 91.0 | 72.0 | 107.0 | 84.0 | 91.0 | 71.0 | 100.0 | 76.0 | 115.0 | 91.0 |
| 25.0 | 99.0 | 78.0 | 119.0 | 94.0 | 138.0 | 101.0 | 116.0 | 90.0 | 129.0 | 98.0 | 149.0 | 108.0 |
| 35.0 | 121.0 | 96.0 | 146.0 | 115.0 | 171.0 | 126.0 | 139.0 | 108.0 | 155.0 | 117.0 | 185.0 | 135.0 |
| 50.0 | 145.0 | 115.0 | 175.0 | 138.0 | 209.0 | 154.0 | 164.0 | 128.0 | 183.0 | 139.0 | 225.0 | 164.0 |
| 70.0 | 183.0 | 145.0 | 221.0 | 175.0 | 269.0 | 198.0 | 203.0 | 158.0 | 225.0 | 170.0 | 289.0 | 211.0 |
| 95.0 | 220.0 | 175.0 | 265.0 | 210.0 | 328.0 | 241.0 | 239.0 | 186.0 | 270.0 | 204.0 | 352.0 | 257.0 |
| 120.0 | 253.0 | 201.0 | 305.0 | 242.0 | 382.0 | 280.0 | 271.0 | 211.0 | 306.0 | 233.0 | 410.0 | 300.0 |
| 150.0 | 290.0 | 230.0 | 334.0 | 261.0 | 441.0 | 324.0 | 306.0 | 238.0 | 343.0 | 261.0 | 473.0 | 346.0 |
| 185.0 | 329.0 | 262.0 | 384.0 | 300.0 | 506.0 | 371.0 | 343.0 | 267.0 | 387.0 | 296.0 | 542.0 | 397.0 |
| 240.0 | 386.0 | 307.0 | 459.0 | 358.0 | 599.0 | 439.0 | 395.0 | 307.0 | 448.0 | 343.0 | 641.0 | 470.0 |
| 300.0 | 442.0 | 352.0 | 532.0 | 415.0 | 693.0 | 508.0 | 446.0 | 346.0 | 502.0 | 386.0 | 741.0 | 543.0 |
Our websites
Select your country to find our products and solutions
-
Africa
- Africa
- Ghana
- Ivory Coast
- Morocco
- North West Africa
- Americas
- Asia
- Europe
- Oceania
